| Unit is a Single Phase |
Unit is a Single Phase |
| 240 Volts |
208 Volts |
| 28.8 kW (kilowatts) |
21.6 kW |
Minimum (incoming)
service:
120 amp service |
Minimum (incoming)
service:
105 amp service |
Minimum required circuit
breaker:
3 x 50 amp breakers |
Minimum required
circuit breaker:
3 x 50 amp breakers
|
|
Building wiring:
3 x 8 gage copper wire
|
Building wiring:
3 x 8 gage
copper wire |
|
|
Maximum temperature increase above ambient water
temp:
|
Maximum temperature increase above ambient water
temp: |
|
@ 1.50 gallons per
minute:
the temperature will increase 92° |
@ 1.50 gallons per
minute:
the temperature will increase 92° |
@ 2.25 gallons per minute:
the temperature will increase 87° |
@ 2.25 gallons per minute:
the temperature will increase 66° |
@ 3.00 gallons per minute:
the temperature will increase 66° |
@ 3.00 gallons per minute:
the temperature will increase 49° |
@4.50 gallons per
minute:
the temperature will increase 44°
|
@4.50 gallons per
minute:
the temperature will increase 33°
|
Minimum water flow to activate
unit:
0.87 gallons per minute,
3.3 liter per minute |
Minimum water flow to activate
unit:
0.87 gallons per minute,
3.3 liter per minute |
Nominal Water Volume
(water inside the unit at any one time):
0.39 gallons / 1.5 liters |
Nominal Water Volume (water inside the
unit at any one time):
0.39 gallons / 1.5 liters |
|
Unit Weight:
24.25 lbs / 11 kilograms |
Unit Weight:
24.25 lbs / 11 kilograms |
Dimensions:
21 3/4" w x 14 1/2" h x
4 5/8" d
|
Dimensions:
21 3/4" w x 14 1/2" h x 4 5/8" d |
Working pressure:
150 psi / 10 BAR |
Working pressure:
150 psi / 10 BAR |
Tested to pressure:
300 psi / 20 BAR |
Tested to pressure:
300 psi / 20 BAR |
Water Connections:
3/4" NPT |
Water Connections:
3/4" NPT |
|
