| Household Application: |
Commercial Applications: |
|
| Unit is a Single Phase |
Unit is a Single Phase |
| 240 Volts |
208 Volts |
| 24 kW (kilowatts) |
18 kW |
Minimum (incoming)
service:
100 amp service |
Minimum (incoming)
service:
88 amp service |
Minimum required circuit
breaker:
2 x 60 amp breakers |
Minimum required
circuit breaker:
2 x 60 amp breakers
|
|
Building wiring:
2 x 6 gage copper wire
|
Building wiring:
2 x 6 gage
copper wire |
|
|
Maximum temperature increase above ambient water
temp:
|
Maximum temperature increase above ambient water
temp: |
|
@ 1.50 gallons per
minute:
the temperature will increase 92° |
@ 1.50 gallons per
minute:
the temperature will increase 82° |
@ 2.25 gallons per minute:
the temperature will increase 73° |
@ 2.25 gallons per minute:
the temperature will increase 54° |
@ 3.00 gallons per minute:
the temperature will increase 54° |
@ 3.00 gallons per minute:
the temperature will increase 41° |
@4.50 gallons per
minute:
the temperature will increase 37° |
@4.50 gallons per
minute:
the temperature will increase 27° |
Minimum water flow to activate
unit:
0.58 gallons per minute,
2.2 liter per minute |
Minimum water flow to activate
unit:
0.58 gallons per minute,
2.2 liter per minute |
Nominal Water Volume
(water inside the unit at any one time):
0.26 gallons / 1.0 liters |
Nominal Water Volume (water inside the
unit at any one time):
0.26 gallons / 1.0 liters |
|
Unit Weight:
18 lbs / 8.1 kilograms |
Unit Weight:
18 lbs / 8.1 kilograms |
Dimensions:
14 9/16" w x 14 1/2" h x
4 5/8" d
|
Dimensions:
14 9/16" w x 14 1/2" h x 4 5/8" d |
Working pressure:
150 psi / 10 BAR |
Working pressure:
150 psi / 10 BAR |
Tested to pressure:
300 psi / 20 BAR |
Tested to pressure:
300 psi / 20 BAR |
Water Connections:
3/4" NPT |
Water Connections:
3/4" NPT |
